HNL-35EL Electric Forklift Overview
The HNL-35EL is a electric forklift from Huanan Heavy Industry, a leading Chinese manufacturer of heavy industrial vehicles and port machinery. This electric forkl…
Description
HNL-35EL Electric Forklift Overview
The HNL-35EL is a electric forklift from Huanan Heavy Industry, a leading Chinese manufacturer of heavy industrial vehicles and port machinery. This electric forklift is engineered for high-load, high-duty applications with electric drivetrain options and low operating costs. We supply the machine with full spare parts support worldwide.
Key Advantages
- Rated Load: 3500
- Operating Weight: 12500 kg
- Power Type: Electric
- Rated Power: 80
- Overall Length: 7540 mm
Technical Specifications
| Rated Load | 3500 |
| Power Type | Electric |
| Rated Power | 80 |
| Rated load | 3500 kg |
| Operating Weight | 12500 kg |
| Bucket Capacity | 1.7 m³ |
| Max. Up digging Force | 100 kN |
| Total cycle time | ≤10.5 s |
| Travel Speed | 前进1档/2档：12/32Forward1st/2nd Gear: 12/32后退挡Reverse Gear: 24 km/h |
| Battery Type | 磷酸铁锂 LFP － |
| Manufacturer | 宁德时代CATL |
| Capacity | 210 kWh |
| Rated Voltage | 618 V |
| IP Electric Box IP Rating | IP68 h |
| Charging Station Interface | 国标/美标/欧标GB/T/CCS1/CCS2 － |
| Travel Motor Rated Power | 110 kW |
| Travel Motor Protection Rating | IP67 |
| Travel Motor Ambient Temperature | （－35） ~ 85 ℃ |
| Travel Motor Cooling Method | 水冷Water Cooling |
| Hydraulic Motor Rated Power | 80 kW |
| Hydraulic Motor Protection Rating | IP67 |
| Hydraulic Motor Ambient Temperature | （－35） ~ 85 ℃ |
| Hydraulic Motor Cooling Method | 水冷Water Cooling |
| Model | 定量系统Proportional System － |
| Operating Mode | 液压先导Hydraulic Pilot Operation － |
| Fuel Capacity | 150 |
| Steering gear Model | 同轴流量放大Coaxial Flow Amplification － |
| Control Mode | 全液压Full Hydraulic － |
| Travel brake | 全液压Full Hydraulic － |
| Parking Brake | 软轴操作soft shaft operation － |
| Transmission Gear | 前2后1Front 2, Rear 1 － |
| Transmission Type | 行星式Planetary Type － |
| Type of Drive Axle | 干式Dry Type － |
| Tire model | 17.5-25/16PR |
| Overall Length | 7540 mm |
| Overall Height | 3300 mm |
| Overall Width | 2425 mm |
| Max.Dumping Height | 3000 mm |
| Dumping Distance 45°Angle | 1239 mm |
| Turning Radius (External) | 6007 mm |
| Maximum Discharge Angle at Highest Position | 45° － |
| Ground Clearance | 424 mm |
| Wheelbase | 2880 mm |
| Wheel Tread | 1911 mm |
