Huanan HNFY80-600 — Custom Special Vehicle
HNFY80-600 Custom Special Vehicle Overview
The HNFY80-600 is a custom special vehicle from Huanan Heavy Industry, a leading Chinese manufacturer of heavy industrial vehicles and port machinery. This …
Description
HNFY80-600 Custom Special Vehicle Overview
The HNFY80-600 is a custom special vehicle from Huanan Heavy Industry, a leading Chinese manufacturer of heavy industrial vehicles and port machinery. This custom special vehicle is engineered for high-load, high-duty applications with electric drivetrain options and low operating costs. We supply the machine with full spare parts support worldwide.
Key Advantages
- Rated Load: 8000
- Power Type: 柴油
- Rated Power: 97
- Load center: 600 mm
- Wheelbase: 2800 mm
Technical Specifications
| Rated Load | 8000 |
| Power Type | 柴油 |
| Rated Power | 97 |
| Load center | 600 mm |
| Wheelbase | 2800 mm |
| Weight | kg 自重 Weight |
| Mast/carriage tilt angle(front/rear) | 1015 |
| Height of mast lowered | 3790 mm |
| Lift height | 3000 mm |
| Height to head guard(height to cab) | 3050 mm |
| Overall length(without forks) | 3705 mm |
| Overall width | 2580 mm |
| Fork dimension | 1520X160X80 mm |
| Min.Turning radius | 5800 mm |
| Travel speed(loaded/unloaded) | 22/25 km/h |
| Max.lifting speed(loaded/unloaded) | 300/350 mm/s |
| Engine | 东风康明斯 |
| Rated output/ Speed | 97/2200 功率/转速 Rated output/ Speed |
| Emission | 国三/EURO III |
Why Buy From CMPartsCN
As an export partner of Huanan Heavy Industry, CMPartsCN offers the HNFY80-600 custom special vehicle at factory-direct prices with complete documentation, flexible payment terms and worldwide delivery. Contact us for a quotation.
