6.7-ton wheel loader with Yuchai YCF3050-T450 engine, China Stage IV. 35 kN digging force, 30 km/h travel speed, 110 L fuel tank. Ideal for construction and agriculture.
JINGONG JGM9075M-10Eco — 6.7 Ton Wheel Loader (China Stage IV)
The JINGONG JGM9075M-10Eco is a 6.7-ton wheel loader built to China Stage IV emission standards, offering a powerful balance of digging force, fuel economy, and operator comfort. Equipped with the Yuchai YCF3050-T450 engine (36.8 kW / 2,200 rpm), it delivers exceptional breakout force and smooth hydraulic performance for construction, agriculture, and material handling applications.
Key Features
China Stage IV compliant — meets latest Chinese emission standards, suitable for EU Stage V with configuration
Powerful Yuchai engine — 36.8 kW / 2,200 rpm with average fuel consumption under 4.5 L/h
High digging force — 35 kN breakout force for tough loading conditions
Large fuel tank — 110 L capacity for extended shift operation
Low cab noise — ≤77.5 dB(A) for operator comfort
Excellent travel speed — up to 30 km/h for fast site movement
Hydraulic system — 150 L/min max flow at 24 MPa
OEM custom available — custom paint, decals, and branding
Technical Specifications
Engine
Engine model
Yuchai YCF3050-T450
Rated power / speed
36.8 kW / 2,200 rpm
Average fuel consumption
<4.5 L/h
Emission standard
China Stage IV (Euro-equivalent)
Performance
Operating weight
6,670 kg
Bucket capacity
0.3 m³
Max. digging force
35 kN
Max. traction force
45 kN
Max. travel speed
30 km/h
Max. gradeability
50%
Swing speed
10.5 r/min
Cab noise
≤77.5 dB(A)
Hydraulic System
Max. hydraulic flow
150 L/min
Relief valve pressure
24 MPa
Dimensions
Overall length
5,985 mm
Overall width
1,980 mm
Overall height
2,910 mm
Wheelbase
2,380 mm
Track width
1,525 mm
Tire type
8.25-16
Tire grounding width
440 mm
Min. ground clearance
310 mm
Platform width
1,980 mm
Counterweight ground clearance
1,095 mm
Working Range
Max. digging reach
6,550 mm
Max. digging depth
3,280 mm
Max. digging height
6,870 mm
Max. dumping height
5,020 mm
Min. front radius
2,383 mm
Min. tail radius
1,830 mm
Boom length
3,400 mm
Arm length
1,900 mm
Bucket width (std.)
700 mm
Dozer Blade
Blade width
1,980 mm
Max. blade rise
394 mm
Max. blade drop
90 mm
Capacities
Fuel tank capacity
110 L
Hydraulic oil tank capacity
130 L
Specifications subject to change without prior notice. Pictures may differ from actual product.
➡️ Contact us for pricing, lead time, or a factory video tour of the JGM9075M-10Eco.
