Features
Equipped with Weichai WP6 National III electronic-control high pressure common rail engine,it features low speed torque,energy saving and environmental protection.
JinGong 50 planetary power shift transmission and single-stage four-element double-turbine torque converter ensure high reliability.
Double pump conflux,steering priority hydraulic system features high efficiency and low energy consumption.
Full hydraulic coaxial flow steering amplification system enables light and flexible steering,and reliable work.
The hydraulic fuel tank uses high-precision paper filter element in the oil suction and oil return pipeline,which ensures the cleanliness of the hydraulic system.
Articulated front and rear frame for high load bearing capacity and good stability.
Single rocker arm Z-shaped tipping mechanism,optimized design of working device,for big breakout force and lifting force.
The structural parts are subject to finite element analysis,and the key hinge joints adopt dustproof design,which ensures good lubrication of the pin shaft.
The working device can be automatically leveled,which contributes to reduced work cycle time and high efficiency.
The service brake adopts air-over-hydraulic caliper disc brake,and the parking brake adopts flexible shaft controlled caliper brake.
The elastic short absorption cab offers wide view and good work environment.
Intelligent instruments system offers real time monitoring of the overall working conditions.
Three power modes:“heavy load”,“medium load”and“light load”can be selected according to different working conditions to achieve fuel economy and consumption reduction.
Parameter
| Item | Parameters | |
| Machine weight kg | 11500 | |
| Rated load kg | 3500 | |
| Bucket capacity m3 | 2.0 | |
| Dump height mm | 3125 | |
| Dump reach mm | 1155 | |
| Max traction kN | ≥100 | |
| Max breakout force kN | ≥95 | |
| Dimension (LxWxH) mm | 7640×2460×3200 | |
| Boom lifting time s | ≤5.5 | |
| Total cycling time s | ≤10.5 | |
| Wheelbase mm | 2870 | |
| Min. Turning radius(outer edge of bucket)mm | 6415 | |
| Rated power kW | 105 | |
| Travel speed | Forward gear I km/h | 0～11 |
| Forward gear II km/h | 0～38 | |
| Reverse gear I/II km/h | 0～16 | |
| Fuel tank volume L | 210 | |
| Hydraulic tank volume L | 210 | |
| Parameters of variant working device | |||
| Item | Rock bucket | Extra-large bucket | Unit |
| Bucket capacity | 1.3 | 2.5 | m3 |
| Rated load | 3500 | 3500 | kg |
| Machine weight | 11450 | 11720 | kg |
| Dump height | 3395 | 3090 | mm |
| Dump reach | 1090 | 1400 | mm |
| Overall length | 7500 | 7760 | mm |
| Min. Turning radius(outer edge of bucket) | 6265 | 6555 | mm |
| The structure and parameters are subject to change without prior notice due to technical progress. If the sample product is different from the actual product in some way, the actual product shall prevail. | |||
Optional components
Single cooling/cooling and heating air conditioner
Laiyang axle
Pilot control
Auxiliary blade for coal bucket
Sliding fork
Quick coupler
Standard configuration
Weichai Power WP6 National III electronic control engine.
JinGong 50 planetary power shift transmission.
Single-stage four-element double turbine hydraulic torque converter.
Yunyu drive axle.
Sunshade curtain,silk enclosure mat,heater,etc.
New aluminum water tank,with intercooler,torque converter oil cooler and hydraulic oil cooler.
New type waterproof connector harness,intelligent instruments,fuel sensor,GPS.
